FOUNDATIONAIR BRAKESIncludes:Foundation Air BrakeHardware KitsCamshafts/CamshaftRepair KitsAutomatic Slack AdjustersAir Brake ChambersAir Wedge Brakes

10Place the camshaft head thrust washer onto the camshaft and lubricate the camshaft bushing journals before installingit. This makes camshaft install

11TECH TIPSAUTOMATIC SLACK ADJUSTERS(Product Code 108)FUNCTIONAs with a manual slack adjuster, Automatic Slack Adjusters multiply the linearforce exer

12ADJUSTING SENSING METHODS1) Stroke SensingIn sensing push rod stroke, several variables come into play. Push rod stroke becomes longer when any one

13TECH TIPSAutomatic Slack AdjustersEUCLID/HALDEXFeatures Benefits & AdvantagesUnhanded design Euclid/Haldex Automatic Slack Adjusters fit both le

14CREWSON BRUNNERAUTO SLACK SMART — MANUAL SLACK EASYFeatures Benefits & AdvantagesClearance AND load sensing Less likely to overadjust than strok

15TECH TIPSTHE BRAKE CHAMBERThe Brake Chamber converts compressed airinto mechanical energy. This conversion isaccomplished by supplying compressed ai

16GENERAL INSTRUCTIONSFOR SEALED TYPE SPRING BRAKESThere are two basic areas of failure related to service and combination chambers: Mechanical and p

17TECH TIPSAir Brake ChambersMECHANICAL RELEASE OF SPRING BRAKE -ALL TYPESDANGER: Do not attempt to mechanically release (cage) the spring when spring

18AVAILABLESTROKE(INCHES)CHAMBERTYPEMAXIMUMMINIMUMRECOMMENDED CHAMBER STROKE RANGE20 2 1/4" (Should be as -1 1/2"1 3/8"24 2 1/4" s

19TECH TIPSAir Brake ChambersCOMBINATION SERVICE/SPRING BRAKE INSTALLATION INSTRUCTIONS (CONT.)5. Connect the service and emergency air line to the pr

2TECH TIPSFUNCTIONAir brake hardware kits are designed to provide all the components required to achieve maximum lining life, stoppingpower, and stabi

20TECH TIPSAir Wedge Brakes provide a good braking system when they are serviced correctly. They are more complicated inoperation and service than S-C

21TECH TIPSAir Wedge BakesOPERATIONWhen air is applied to the air chamber, the air chamber push rod pushes a wedge between two rollers in the wedgeass

22INSUFFICIENT BRAKEBRAKES GRABBINGBRAKE DRAGGINGSPRING BRAKESDON'T HOLD1. Brakes were not adjusted properly at initial installation.2. Automatic

23TECH TIPSAir Wedge BrakesBENDIX1. Weak or broken adjuster lever spring.2. Broken adjuster lever pin.3. Worn or broken adjuster lever or cap teeth.4.

24AUTOMATIC BRAKE ADJUSTMENTAir Wedge Brakes include automatic adjuster assemblies that maintain the proper brake lining-to-drum clearance. Thecompone

25TECH TIPSAir Wedge BrakesBRAKE SHOESBoth Bendix and Rockwell "Stopmaster" brake shoes must be installed correctly in the brake assembly.Be

26TECH TIPSFUNCTIONAir brake tubes and hoses are the arteries of a vehicles air system. Their purpose is to transfer air from the air tanks tovalves a

27TECH TIPSAir HoseREPLACEMENTThe leaking or in need of replacement hose should be removed immediately. Removal and replacement is normallyeasy when a
